CJX8 series B12 electric magnetic contactor AC contactors
Inquire Now
Technical Specification
Type B9 B12 B16 B25 B30 B37 B45
The highest control power (KW) 220V 2.2 3 4 6.5 9 10 13
380V 4 5.5 7.5 11 15 18.5 22
380V 4 5.5 7.5 11 15 18.5 22
660V 4 5.5 7.5 11 15 18.5 22
Technical specification
| Technical Specification | ||||||||
| Type | B9 | B12 | B16 | B25 | B30 | B37 | B45 | |
| The highest control power (KW) | 220V | 2.2 | 3 | 4 | 6.5 | 9 | 10 | 13 |
| 380V | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | |
| 380V | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | |
| 660V | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | |
| Rated heating current Ith (A) | 16 | 20 | 25 | 40 | 45 | 45 | 60 | |
| Rated working current AC2/AC3/AC4 |
380V | 8.5 | 11.5 | 15.5 | 22 | 30 | 37 | 44 |
| 660V | 3.5 | 4.9 | 6.7 | 13 | 17.5 | 21 | 25 | |
| Rated holding power of a holding coil/pull-in (VA/W) |
9/2.2 60/50 |
9/2.2 60/50 |
9/2.2 60/50 |
10/3 85/65 |
10/3 85/65 |
22/5 175/125 |
22/5 125 |
|
Trade & Market
————————————————————————————-
Company Profiles
Mingguang Hecheng Electrical Co.,Ltd. is located in Anhui, China, produces different kinds of
products with high quality and reasonable price. Such as Contactors (including DP contactors, LC1
series contactors , SK series contactors , etc. ), Transformers, Relays, Starters, Fuses, Circuit Breakers,
Switches, Cable Wires, etc.
We are always at your service!
Welcome to be our agent !!
Welcome to visit our factory at anytime !!!
