CNC STIRRUP BENDER WGZP16
Inquire NowDescription
The CNC Stirrup Bender WGZP16 is a state-of-the-art machine designed for precision and efficiency in stirrup bending. With CNC control, this automatic stirrup bender offers seamless operation for various wire diameters ranging from 8-16mm for bars and 5-12mm for coils. It features bidirectional bending capabilities, allowing for enhanced versatility in production. The WGZP16 is equipped with a servo motor paired with a pneumatic system for optimal performance, ensuring that you achieve the highest quality bends with ease.
Its user-friendly control console is fitted with a touch screen, providing intuitive navigation and monitoring of operations. The machine supports a maximum stirrup size of 1380mm diagonally, with a minimum side length of 150mm. Additionally, the automatic wire inserting unit accommodates both bar and coil, streamlining your workflow and enhancing productivity.
Specifications
| Feature | Details |
|---|---|
| Model | WGZP16B |
| Wire Diameter | 8-16mm (bar), 5-12mm (coil) |
| Bending Type | Bidirectional |
| Motor Type | Servo-motor with pneumatic |
| Control System | CNC PLC Control |
| Maximum Stirrup Size | 1380mm (diagonal) |
| Minimum Stirrup Size | 150mm (side) |
| Wire Inserting Unit | Automatic for both bar and coil |
| Control Console | Touch Screen |
Additional Information
For optimal performance and longevity, regular maintenance of the CNC Stirrup Bender WGZP16 is recommended. Ensure that the machine is kept clean and that all moving parts are properly lubricated. Always refer to the user manual for specific operational guidelines and safety instructions.
