Compressor
Inquire NowDescription
The Jichai Compressor is a versatile and powerful solution designed for a wide range of industrial applications. With a portfolio that includes eight series and nearly 100 types of compressors, it caters to various needs, from gas collection and treatment to oil and gas processing. This compressor offers a power range from 10 to 7500 kW, making it suitable for both small and large-scale operations. Its robust design ensures reliability and efficiency, while its capability to handle multiple working mediums such as natural gas, coal bed gas, and air makes it an ideal choice for diverse environments.
Specifications
| Model | Specifications |
|---|---|
| Z series |
Power range: 85～630kW Gas displacement: 0.1～100×104 Nm3/d Maximum exhaust pressure: 35MPaG Application area: Gas collecting, oil and gas treatment, gas lifting, light hydrocarbon recovery. Working medium: Natural gas, coal bed gas, shale gas, oil field associated gas, air, nitrogen, etc. |
| R series |
Power range: 10～7500kW Gas displacement: 0.1～500×104 Nm3/d Maximum exhaust pressure: 52MPaG Application area: Gas collecting, gas production and injection, oil and gas treatment, natural gas liquefaction. Working medium: Natural gas, coal bed gas, shale gas, etc. |
| D series |
Power range: 10～7500kW Gas displacement: 0.1～500×104 Nm3/d Maximum exhaust pressure: 52MPaG Application area: Similar to R series. Working medium: Natural gas, coal bed gas, shale gas, etc. |
| C series |
Power range: 10～7500kW Gas displacement: 0.1～500×104 Nm3/d Maximum exhaust pressure: 52MPaG Application area: Similar to R series. Working medium: Natural gas, coal bed gas, shale gas, etc. |
| Q series |
Gas inlet pressure: 1.0～2.4MPaG Gas outlet pressure: 17～50MPa Gas displacement: 25～100Nm3/min Application area: Drilling operations of pure air and nitrogen, underbalanced drilling in China. |
| Integrated oxygen reducing and pressurizing device |
Gas inlet pressure: 1.0～2.4MPaG Gas displacement: 25～100Nm3/min Maximum exhaust pressure: 17～50MPa Working medium: Air, nitrogen, oxygen-reducing air. Application area: Gas injection, gas drilling, pipeline pressure testing. |
Additional Information
Each compressor series is engineered to meet specific industrial demands, ensuring optimal performance across various applications. The versatility in working mediums allows for adaptability in different operational contexts, making Jichai compressors a reliable choice for your gas handling and processing needs.
