concrete block machine
Inquire NowDescription
Concrete Block Machine is a multifunctional block machine designed to produce a variety of blocks such as bricks, pavers, and curbstones by simply changing the molds. The machine features a specialized storage and material system that ensures precise feeding, preventing external material interference, which results in high-density products. It employs a synchronization vibration mechanism, allowing for adjustable frequencies to optimize material vibration based on different techniques, enhancing the production process.
Equipped with a fault diagnosis system, the machine provides warning signals to facilitate quick fault elimination. Additionally, it integrates a long-distance control system for effective monitoring and control. This user-friendly machine utilizes a PLC intelligent control system, which includes a man-machine interface, comprehensive logic control, production programming, malfunction diagnosis, and remote control capabilities, requiring only basic training for operators.
The machine can produce a wide range of products, including color-face bricks, through-body tiles, lock linkage blocks, road curb bricks, hydraulic blocks, hollow blocks, perforated bricks, and standard bricks.
Specifications
| Attribute | Specification |
|---|---|
| Overall Dimension | 7500×2500×3020 (mm) |
| Rated Pressure | 21 MPa |
| Main Vibration Form | Platform Vibration |
| Acceleration of Vibration | 15-20 g |
| Cycle Time | 15-20 seconds |
| Vibrating Frequency | 2800-4500 rolls/minute |
| Exciting Force | 100 KN |
| Motors Power | 49 KW |
| Weight | 11 T |
| Pallet Size | 1220×900 (mm) |
| Raw Materials | Crushed stone, sand, cement, dust, coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes. |
| Applied Products | Concrete blocks, solid/hollow/cellular masonry products, paving stones, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc. |
Additional Information
The concrete block machine is engineered for efficiency and versatility, making it ideal for various construction projects. Its robust design ensures durability and reliability in high-demand environments.
