The construction hoist by Fangyuan represents a pinnacle of engineering in the lifting industry, showcasing advanced industrial design and exceptional control performance. This innovative product not only enhances operational safety but also emphasizes comfort for its users. The new generation SC series hoists leverage modular structures and ergonomic designs, allowing for impressive adaptability and reliability. With a maximum lifting height of up to 300 meters, these hoists are equipped with patented technologies that position them at an advanced level within China’s market, while also gaining traction in international markets such as Russia, Turkmenistan, and Vietnam.
Key features of this construction hoist include:
- The cage drive system includes a buffering device for stable movement.
- Ergonomically designed cage interiors enhancing user comfort.
- Unique structural design with applied patents for improved safety and efficiency.
- Technological advancements ensuring minimal malposition differences in guide rails.
- High-quality components that guarantee the machine’s reliability.
- Precise assembly and accurate drive mechanisms.
- Customized solutions for specialized projects.
- Comprehensive safety devices that ensure robust control systems.
The SC series also boasts special designs, such as reinforced guide rails and configurations suitable for specific applications like cooling towers. Additionally, double cage construction elevators can be adapted to single cage types, such as the SCD200 model.
Specifications
| Model | SC200/200 | SC200/200BP | SCD200/200 | SC200/200B | ||
|---|---|---|---|---|---|---|
| Configuration | Standard type | Frequency conversion | Counterweight type | Export type | ||
| Rated load | 2000/2000 kg | 2000/2000 kg | 2000/2000 kg | 2000/2000 kg | ||
| Cage size L×W×H | 3×1.3×2.2 m | 3×1.3×2.2 m | 3×1.3×2.2 m | 3×1.3×2.2 m | ||
| Passengers | 16/16 | 16/16 | 16/16 | 16/16 | ||
| Max. lifting height | 150 m | 300 m | 150 m | 150 m | ||
| Max. height of free end | 9 m | 9 m | 9 m | 9 m | ||
| Lifting speed | 33 m/min | 0~60 m/min | 33 m/min | 33 m/min | ||
| Capacity of small hoist | 200 kg | 200 kg | 200 kg | 200 kg | ||
| Std. section L×W×H | 650×650×1508 mm | |||||
| Electric motor | Type | Disc brake electric motor | ||||
| Power | kW | 11×3/11×3 | 11×3/11×3 | 11×2/11×2 | 11×3/11×3 | |
| Speed limiter | Action speed | m/s | 1.2 | 1.45 | 1.2 | 1.2 |
| Rated brake load | kN | 40 | 40 | 30 | 40 | |
Additional Information
The above parameters are subject to change without prior notice; please refer to the actual product for confirmation. Note that both cage sizes of 3×1.3×2.2 and 3.2×1.5×2.4 are available for each model.
