conventional lathe GH-1440K
Inquire Now
Max.swing over bed: Ф356mm
Max.swing over carriage: Ф210mm
Spindle bore: Ф40mm
Spindle speed: 40-1800rpm
Main motor: 2.4kw
TECHNICAL SPECIFICATION
| ITEM | CH-1440K |
| MACHINING | |
| Max.swing diameter over bed | Ф356mm |
| Max.swing diameter over carriage | Ф210mm |
| Max.swing in gap | Ф508mm |
| Width of bed | 260mm |
| Max.workpiece length | 1000mm |
| SPINDLE | |
| Taper of spindle bore | M.T.No.5 |
| Diameter of spindle hole | Ф40mm |
| Number of speed steps | 12 |
| Spindle speed | 40-1800rpm |
| Spindle nose | D4 |
| THREAD &FEEDING | |
| Metric pitch threads |
0.4~7mm(37 kinds) Metric system 0.45~7.5mm(23 kinds) Inch system |
| Whitworth pitch threads |
4~56T.P.I (28 kinds) Metric system 4-112T.P.I (40 kinds) Inch system |
| Range of longitudinal feeds | 0.043-0.653(0.0012″-0.0294″) |
| Range of cross feeds | 0.024-0.359(0.0004″-0.0103″) |
| LEADSCREW | |
| Diameter of leadscrew | Ф22mm |
| Pitch threads of leadscrew | 4mm or 8T.P.I. |
| TAILSTOCK | |
| External diameter | Ф45mm |
| Taper of bore | M.T.No.3 |
| Max.traverse | 120mm |
| OTHER | |
| Coolant pump motor power | 0.04kw |
| Power of main motor | 2.4kw |
| Overall dimensions(Lx Wx H) | 1900X710x1170mm |
| Net weight | 1250kg |
|
The descriptions, illustrations and specifications given here in are subject to alteration without notice and thus without any obligation. |
|
