corrugated iron sheet making roll forming machine

Inquire Now

#### **Description**
The corrugated iron sheet making aluzinc roll forming machine is an advanced and automated solution designed for efficiently producing high-quality corrugated sheets. This machine excels in processing color steel plates, making it ideal for various construction and roofing applications. With a robust construction and user-friendly operation, it offers significant productivity, producing sheets at a rate of 8-12 meters per minute.

#### **Specifications**

Feature Details
Suitable to Process Color steel plate
Width of the Plate 1000mm
Thickness of the Plate 0.3-0.8mm
De-coiler Manual, can load 5 tons raw material
Rollers for Forming 14 rows
Diameter of the Roller 80mm
Rolling Material Carbon Steel 45#
Main Motor Power 4kw
Productivity 8-12m/min
Cutting Method Hydraulic mould cutting
Material of the Cutting Blade Cr12
Hydraulic Cutting Power 3kw
Processing Precision Within 1.00mm
Control System Delta PLC control
Side Panel of Machine 14mm
Main Structure of the Machine 300 H steel
Weight About 4.6T
Dimensions 7.5*1.6*1.2m
Voltage 380V 50Hz 3 phases (changeable as needed)
Certificate CE/ISO

#### **Additional Information**
**Packaging Details:**
Main machine is nude, and the computer control box is packed with a wooden frame.

**Delivery Detail:**
20 days.
