corrugated iron sheet making roll forming machine
Inquire NowDescription
Corrugated Iron Sheet Making Aluzinc Roll Forming Machine is designed for efficient processing of color steel plates into corrugated sheets. This machine combines high durability with advanced technology, enabling businesses to produce quality metal roofing materials with precision and speed. Its robust construction and user-friendly controls make it suitable for both small and large scale production lines.
Specifications
| Feature | Details |
|---|---|
| Suitable to Process | Color steel plate |
| Width of the Plate | 1000mm |
| Thickness of the Plate | 0.3-0.8mm |
| De-coiler | Manual one, can load 5 tons raw material |
| Rollers for Forming | 14 rows |
| Diameter of the Roller | 80mm |
| Rolling Material | Carbon Steel 45# |
| Main Motor Power | 4kw |
| Productivity | 8-12m/min |
| Cutting Method | Hydraulic mould cutting |
| Material of the Cutting Blade | Cr12 |
| Hydraulic Cutting Power | 3kw |
| Processing Precision | Within 1.00mm |
| Control System | Delta PLC control |
| Side Panel of Machine | 14mm |
| Main Structure of the Machine | 300 H steel |
| Weight | About 4.6T |
| Dimensions | 7.5*1.6*1.2m |
| Voltage | 380V 50Hz 3phases (changeable as needs) |
| Certificate | CE/ISO |
Additional Information
Packing & Delivery:
| Packaging Details: | Main machine is nude, the computer control box is packed with wooden frame. |
| Delivery Detail: | 20 days |
