Corrugated Roof Profile Making Machine Sheet Metal Forming Machinery
Inquire NowDescription
The Corrugated Roof Profile Making Machine is a state-of-the-art sheet metal forming machinery designed for the efficient production of corrugated metal roofing sheets. This advanced machine incorporates a range of features, including a PLC control system, durable main frame, and an array of configurations that ensure high-quality output with precision. With a forming speed of 10m/min and a robust construction, it is ideal for manufacturers looking to streamline their production process while maintaining high standards of quality.
Specifications
| Attribute | Details |
|---|---|
| Configurations | Manual Uncoiler, Guiding Platform, Coil Strip Leveler, Main Machine Of Roll Forming, Electro-Motor, Cutting Device, Hydraulic Station, PLC Control, Supporter Table |
| Control System | PLC Delta Inverter |
| Main Frame | 250mm H-Beam |
| Main Power | 3 kw |
| Pump Power | 3 kw |
| Power Supply | 380V, 3-Phase, 50Hz |
| Forming Speed | 10m/min |
| Roll Station | 14 stands |
| Roller Diameter | 80mm |
| Hydraulic Pressure | 10-12MPa |
| Forming Size | 988mm |
| Feeding Thickness | 0.3-0.8mm |
| Feeding Width | 1200mm |
| Backboard Thickness | 14mm |
| Chain Size | 20mm |
| Cutter Standard | Cr12 |
| Roller Standard | Cr12 |
| Cr-Plating Size | 0.05mm |
| Overall Size | 7500×1600×1500mm |
| Total Weight | 4T |
Additional Information
For optimal performance, it is recommended to regularly maintain the machine and follow the manufacturer’s guidelines on usage. Ensure that the hydraulic system is checked periodically to maintain efficiency. Warranty details are available upon request.
Production Images
