CUL Listed central air conditioner fuse box 60 amp metallic air conditioner ac disconnect
Inquire NowDescription
The CUL Listed Central Air Conditioner Fuse Box is a robust 60 amp metallic disconnect designed to enhance safety and convenience for your air conditioning system. This essential device allows for easy On/Off control via a pullout handle, ensuring that you can quickly disconnect power when needed. The pullout handle is conveniently stored in a compartment in the OFF position, preventing it from being misplaced. Importantly, the protective shield remains securely in place until the pullout handle is removed, ensuring a safe disconnection of power.
This disconnect is ideal for outdoor applications, featuring a NEMA 3R rain-proof construction that protects the unit from the elements. Its design not only serves to secure your air conditioning system against unauthorized access but also provides peace of mind when leaving your home for extended periods.
Specifications
| Disconnect Type | Model Number | Construction | Main Amp Rating | Wire Size Range | Maximum Horsepower Rating | |
|---|---|---|---|---|---|---|
| Non-Fused Pullout | PDS-60AN | Galvanized Steel | 60 | Al/Cu, 60° or 75°C | 120VAC | 240VAC |
| Non-Fused Pullout | PCDS-60AN | Nonmetallic | 60 | #14-2 | 3 | 10 |
Additional Information
Application: The A/C disconnect serves as a visible solution to prevent unauthorized access to the air conditioning circuit, especially when homeowners leave for an extended period. It can be locked to ensure safety and is designed for outdoor installation with rain-proof features.
