Diamond Segment
Inquire NowDescription
The Diamond Segment is an essential cutting tool designed for precision trimming and slabbing of granite, marble, and other hard materials. Manufactured with high-quality diamond particles, this segment ensures superior performance, longevity, and efficiency in your cutting tasks. Ideal for both professional and DIY applications, the Diamond Segment is engineered to meet the demands of various projects, providing reliable results every time. Its robust construction and versatile dimensions make it suitable for a wide range of cutting machines, enhancing productivity in stone processing.
Specifications
| Diameter (mm) | Segment Dimension LxWxH (mm) | Core Thickness (mm) | Segment Number | Application |
|---|---|---|---|---|
| 900 | 24×6.6/6.2×12/20 | 5.0 | 64 | For trimming and slabbing Granite & Marble etc. |
| 1000 | 24×7.4/6.8×12/20 | 5.0 | 70 | |
| 1100 | 24×7.4/6.8×12/20 | 5.5 | 74 | |
| 1200 | 24×7.5/7.0×12/20 | 5.5 | 80 | |
| 1300 | 24×8.0/7.4×12/20 | 6.0 | 88 | |
| 1400 | 24×9.0/8.4×12/20 | 6.5 | 96 | |
| 1600 | 24×9.2/8.6×12/20 | 6.5 | 108/104 | |
| 1800 | 24×10/9.6×15/20 | 7.0 | 120 | |
| 2000 | 24×10.6/9.6×15/20 | 8.0 | 128 | |
| 2200 | 24×11.5/10.5×15/20 | 8.5 | 136 | |
| 2500 | 24×12.0/11.0×20 | 9.5 | 140 | |
| 3000 | 24×13/12×20/30 | 10 | 160 |
Additional Information
- Model Number: QZDT-6
- Place of Origin: China
