Diesel engine horizontal type water cooled R175A
Inquire NowDescription
The Diesel Engine R175A is a robust and efficient horizontal type, water-cooled engine designed for a variety of industrial applications. This 4-stroke, single-cylinder powerhouse boasts a compression ratio of 22 and operates at a rated speed of 2600 RPM, making it an ideal choice for demanding tasks that require reliability and performance. The R175A is engineered with a prechamber combustion system which enhances fuel efficiency and reduces emissions, ensuring a cleaner operation. Its compact design and powerful output make it suitable for both stationary and mobile equipment.
Specifications
| Attribute | Details |
|---|---|
| Model | R175A |
| Type | Horizontal 4 Stroke |
| Combustion Chamber Type | Prechamber |
| Number of Cylinders | 1 |
| Bore x Stroke (mm) | 75 x 80 |
| Total Displacement (L) | 0.353 |
| Compression Ratio | 22 |
| 1 Hour Rated Power (kW) | 4.85 |
| 12 Hour Rated Power (kW) | 4.41 |
| Rated Speed (r/min) | 2600 |
| Specific Fuel Consumption (g/kW-h) | 280.2 |
| Cooling Method | Water Cooled |
| Starting Method | Handle/Electrical |
Additional Information
The R175A diesel engine is designed for easy handling and operation, catering to both manual and electrical starting methods. Its water-cooled system ensures optimal performance even under heavy loads, making it a reliable choice for various applications.
