Description
The Diesel Engine Single Cylinder LA170 is a robust and efficient power solution designed for various applications. This engine features a compact design while delivering impressive performance, making it ideal for agricultural machinery, generators, and other industrial uses. With a maximum output of 4.2 hp and a continuous output of 3.8 hp, it ensures reliable operation under demanding conditions. Its advanced engineering guarantees durability and longevity, making it a smart investment for those in need of dependable power.
Specifications
| Attribute | Value |
|---|---|
| Model | LA170 |
| Bore * Stroke (mm) / (inch) | 70 * 55 / 2.76 * 2.17 |
| Displacement (cc) / (cu.in.) | 211 / 12.87 |
| Engine Speed (rpm) | 3000 / 3600 |
| Maximum Output (hp) | 3.8 / 4.2 |
| Continuous Output (hp) | 3.4 / 3.8 |
| Power Take Off | Crankshaft or Camshaft (Camshaft PTO rpm is 1/2) |
| Starting System | Recoil or Recoil / Electric |
| Fuel Tank Capacity (L) / (us.gal) | 2.5 / 0.66 |
| Lube Oil Capacity (L) / (us.gal) | 0.75 / 0.20 |
| Dimensions (L * W * H) (mm) / (inch) | 332 * 392 * 416 / 13.0 * 15.4 * 16.3 |
| Net Weight (Recoil) (kg) / (lbs) | 27 / 59.5 |
Additional Information
For optimal performance, ensure regular maintenance of the diesel engine, including timely oil changes and fuel filter replacements. This engine is designed to be user-friendly, making it suitable for both experienced operators and beginners.
