DIGITAL GENERATOR-IG770
Inquire NowDescription
The DIGITAL GENERATOR-IG770 is the perfect blend of power, portability, and quiet operation. Designed for users who need reliable electricity on the go, this generator provides a maximum output power of 0.77kVA, making it suitable for a variety of applications including outdoor events, camping, or as backup power for small appliances. Its advanced inverter technology ensures a stable power supply, ideal for powering sensitive electronics like computers.
Weighing in at only 10.5 kg, its lightweight and compact design allows for easy transport and storage. The generator operates at a low noise level of 60-65 dB(A) at 7 meters, ensuring it won’t disrupt your activities. With a fuel tank capacity of 1.55 liters, it can run continuously for up to 3 hours, providing you with uninterrupted power when you need it most.
Specifications
| Attribute | Details |
|---|---|
| Model | IG770 |
| Rated frequency (Hz) | 50/60 |
| Rated voltage (V) | 230/120-240 |
| Rated current (A) | 3.04/5.82-2.92 |
| Rated speed (r/min) | 6000 |
| Rated output (kVA) | 0.7 |
| Max. output (kVA) | 0.77 |
| DC output | N/A |
| Phase number | Single phase |
| Structure type | Portable, silent |
| Fuel capacity (L) | 1.55 |
| Fuel consumption (g/kW.h) | <550 |
| Continuous running time (hr) (rated output) | 3.0 |
| Noise level (dB(A)/7m) | 60-65 |
| Overall dimension (L×W×H) (mm) | 415×220×360 |
| Net weight (kg) | 10.5 |
| Starting system | Recoil starter |
| Fuel type | Automotive unleaded gasoline |
| Lube oil brand | CD grade or SAE10W-30, 15W-40 |
| Engine Model | KG140 |
| Engine Type | Single cylinder, four-stroke, OHC, vertical, air-cooled |
| Bore×stroke (mm) | 40×30 |
| Displacement (ml) | 37.68 |
| Compression ratio | 8.5:1 |
| Rated power [Kw(r/min)] | 1.0/6000 |
| Ignition system | T.C.I |
| Spark plug | UR5 |
| Lowest fuel consumption (g/kW.h) | 450 |
Additional Information
For optimal performance, it is recommended to use the appropriate lube oil brand and to maintain the generator according to the manufacturer’s guidelines. Ensure the generator is operated in a well-ventilated area and that fuel is handled safely.
