DIRECT DRIVE DRAWWORKS
Inquire NowDescription
The Direct Drive Drawworks revolutionizes the drilling process with its innovative design and advanced technology. This system features double motors that drive the drum directly, eliminating the need for a reduction gear shift mechanism, coupling, and lubrication system. The result is a compact unit that is 40% smaller and 25% lighter than traditional drawworks, significantly reducing the maintenance workload by an impressive 80%.
Equipped with an AC VFD drive, it ensures fast line safety protection and features automatic position control along with upper and lower travel protection for the travelling block. The integrated wire line protection system (WPS) enhances service life, while the direct acting and floating hydraulic disc brake delivers quick response times with automatic clearance adjustment and an integrated hydraulic source. The system also includes a next-generation automatic driller’s control software that provides comprehensive control modes for Rate of Penetration (ROP), Weight on Bit (WOB), deltaP (pressure difference), and torque control, ensuring optimal drilling performance.
Specifications
| Feature | Details |
|---|---|
| Size Reduction | 40% smaller than traditional drawworks |
| Weight Reduction | 25% lighter than traditional drawworks |
| Maintenance Workload | Reduced by 80% |
| Drive Type | AC VFD drive |
| Safety Features | Fast line safety protection, automatic position control |
| Travel Protection | Upper & lower travel protection for travelling block |
| Wire Line Protection System | Yes |
| Brake System | Direct acting and floating hydraulic disc brake |
| Control Software | Integrated automatic driller’s control software with multiple modes |
Additional Information
- Improves efficiency and reduces downtime with less maintenance required.
- Advanced control features enhance drilling precision and performance.
