Direct Drive Portable Air Compressor-ZB-0.08/8
Inquire NowDescription
The Direct Drive Portable Air Compressor ZB-0.08/8 is an efficient and reliable solution for all your air compression needs. Designed for both professional and personal use, this portable compressor is powered by a robust 1.1 KW motor, delivering a maximum pressure of 115 Psi (8 bar). The compressor boasts impressive displacement rates, offering 158 L/min at 2850 r/min and up to 190 L/min at 3450 r/min, ensuring quick inflation and air supply for various applications.
With a tank capacity of 24 liters, this compressor is capable of maintaining air pressure for extended usage without frequent refills. Its compact design, with dimensions of 59 cm in length, 29 cm in width, and 62 cm in height, makes it easy to transport and store. Designed with user convenience in mind, it operates at a noise level of 88 dB(A), making it suitable for both indoor and outdoor environments.
Specifications
| Attribute | Unit | Value |
|---|---|---|
| Model | ZB-0.08/8 | |
| Code | SGBM9023 | |
| Power | KW | 1.1 |
| Power | HP | 1.5 |
| Cylinder | mm | Φ42×1 |
| Rated speed | r/min | 2850/3450 |
| Displacement | L/min | 158/190 |
| Displacement | CFM | 5.5/6.6 |
| Discharge pressure | Psi | 115 |
| Discharge pressure | bar | 8 |
| Noise Level | dB(A) | 88 |
| Tank capacity | L | 24 |
| Tank capacity | Usgal | 6.34 |
| Net weight | kg | 23 |
| Outer Size | (L×B×H)cm | 59×29×62 |
Additional Information
– Ideal for a variety of applications including automotive repairs, inflating tires, and powering pneumatic tools.
– Ensure to follow all safety guidelines while using the compressor to maximize its lifespan and efficiency.
