DLV20 Sectional Directional Control Valve
Inquire NowDescription
The DLV20 Sectional Directional Control Valve is a versatile hydraulic solution designed to enhance performance across various applications. Available in configurations ranging from 1 to 8 sections, this valve features multiple spool functions to meet diverse operational needs. The inclusion of load sensing control technology ensures optimized flow rates, regardless of load pressure fluctuations, thereby promoting energy efficiency. With its pressure-compensated flow control, this hydraulic valve guarantees consistent operation under varying conditions.
Engineered for precision, the spool boasts smoothly polished surfaces that enable accurate fluid flow control with minimal leakage. Additionally, the valve’s optimal piping layout design results in low pressure drops, ensuring efficient system performance. Built for safety and reliability, the DLV20 is equipped with essential components such as safety valves, overload valves, charge valves, and check valves, making it an ideal choice for a wide range of applications while facilitating easy maintenance.
Specifications
| Feature | Details |
|---|---|
| Sections Available | 1 to 8 |
| Spool Functions | Various |
| Flow Control Type | Pressure-compensated |
| Control Type | Load sensing |
| Piping Layout Design | Optimal, low pressure drop |
| Loop Type | Parallel circuit |
| Safety Features | Safety valve, overload valve, charge valve, check valve |
Additional Information
- Easy maintenance
- Suitable for a wide range of applications
