Double Head cutting saw for aluminium profile
Inquire NowDescription
The Double Head Cutting Saw for Aluminium Profile, model DSD500X4300, is an exceptional tool engineered for precision cutting of aluminium alloy materials, including curtain walls and window profiles. This machine is also capable of cutting plastic profiles, providing versatility for various applications. Featuring a robust carbide saw blade with a diameter of up to 500 mm, it ensures high-speed and high-precision machining.
With its advanced numerical control technology, the saw can automatically handle profiles of different specifications, achieving cuts to the expected size. The design promotes safety and reliability, with the saw blade moving from the bottom to the top, allowing for larger cutting heights and widths. A digital display provides real-time information on the cutting position, enhancing user-friendliness and operational accuracy.
Specifications
| Feature | Details |
|---|---|
| Power Supply | 380V, 50HZ |
| Cutting Motor Power | 5.9 kW |
| Angle Accuracy | ±0.5 degree |
| Dimensional Accuracy | ±0.1 mm |
| Cutting Motor Rotary Speed | 2800 r/min |
| Operation Air Pressure | 0.6-0.8 MPa |
| Air Consumption | 60 L/min |
| Blade Specification | 500 x 25.4 mm |
| Cutting Length | 400 mm – 4500 mm |
| Cutting Width | 150 mm |
| Max Cutting Section | 135 x 200 mm |
| Cutting Angle | 45, 90 degrees |
| Contour Dimension | 5750 x 1300 x 1500 mm |
| Weight | 2500 kg |
Additional Information
| Main Accessory | Details |
|---|---|
| Saw Blade | 2 pcs |
| Mobile Work Piece Supports | 2 sets |
| Air Gun | 1 pc |
| Complete Tooling | 1 set |
| Certificate | 1 pc |
| Operation Manual | 1 pc |
