Double Layer Corrugated Metal Roofing Sheet Roll Forming Machine IBR Roofing panel double
Inquire NowDescription
The Double Layer Corrugated Metal Roofing Sheet Roll Forming Machine is expertly designed for producing IBR roofing panels, making it an essential tool for modern construction and renovation projects. This machine excels in processing a variety of materials including color steel plates, galvanized sheets, and aluminum coils, ensuring versatility and efficiency. With its advanced technology, it is capable of creating durable and aesthetically pleasing roofing solutions that meet various architectural demands.
Specifications
| Parameter | Description |
|---|---|
| Suitable to process | Color steel plate, galvanized sheet, aluminum coils, etc. |
| Width of the feeding material | 914-1250mm |
| Roller station | 11-18 rows or custom as customer’s requirements |
| Thickness of feeding material | 0.3-0.8mm |
| Productivity | 8-12m/min |
| Rollers’ material | 45# steel |
| Diameter of shaft | 70-80mm |
| Voltage | 380V 50Hz 3 phases |
| Wall thickness of main forming machine | 12-18mm steel plate |
| Main forming machine body | 300-400 mm H steel |
| Motor power | 4-7.5 kw |
| Weight | About 5-15T |
| Custom | According to customer’s requirements |
Additional Information
Guarantee: 12 Months guarantee. If any part of the machine is broken, replacements will be provided; however, if the damage is due to operational error, the buyer will cover shipping costs.
After-sale service: Technicians can be sent to your location to assist with repairs. The buyer is responsible for all associated costs including visa, round-trip tickets, accommodation, and a daily salary of $100.
Product Pictures
