double layer roll forming machine roof sheet roll forming machine wellding Tile Making
Inquire NowDescription
The double layer roll forming machine is an innovative solution designed for efficiently producing roof sheets and tiles. This advanced machine combines two types of tile production in one compact setup, making it ideal for customers with limited operational space. Its reasonable structure and attractive appearance enhance its appeal, while its user-friendly operation ensures ease of use for all operators.
Engineered for high performance, this machine features an automatic PLC control system with a touch screen interface, allowing for seamless operation and monitoring. It’s particularly well-suited for drywall manufacturing and is highly favored in various industrial applications.
Specifications
| Feature | Details |
|---|---|
| Control System | Automatic PLC frequency control, touch screen |
| Roller Steps | 9/11 rows |
| Main Power | 4 kW |
| Pump Power | 4 kW |
| Diameter of Roller | Φ72 mm |
| Max Speed | 12 m/min |
| Feeding Width | 1000 mm |
| Effective Width | 850/840 mm, tolerance ±1/100 |
| Plate Thickness | 0.35-0.6 mm |
| Dimensions of Main Roll Former | 7600 mm × 1300 mm × 1450 mm |
| Roller Material | 45# steel, CNC-machined, heat treated, buffed, surface electroplated with chromium 0.05 mm |
Additional Information
Packaging Details: The main machine is shipped nude, while the computer control box is securely packed in a wooden frame.
Delivery Detail: The estimated delivery time is 20 days.
Usage: Our double layer roll forming machine is widely used in industrial factories, civilian buildings, warehouses, and easy steel building manufacturing, offering a durable and aesthetically pleasing solution.
Warranty: 12 months guarantee. If any part of the machine is broken, replacements will be provided. However, for damages due to operational errors, the buyer is responsible for shipping costs.
After-sale Service: We provide technician support for machine installation and operation training, with the buyer covering travel and accommodation costs.
