DP220
Inquire NowDescription
The DP220 speaker system is designed for audiophiles seeking exceptional sound quality and performance. This comprehensive setup includes a front speaker (DP220), center speaker (DC22), surround speaker (DS22), and a subwoofer (W600/W310), each tailored to deliver an immersive audio experience. The front speaker features a sophisticated driver unit comprising a 20mm tweeter, dual 4” mid-bass drivers, and an 8” woofer, ensuring vibrant sound across a wide frequency range. With a sensitivity of 87 dB and a power handling capacity of 20-150W, the DP220 can handle dynamic soundscapes with ease.
The center speaker (DC22) is optimized for clear dialogue, featuring a similar 20mm tweeter and dual 4” mid-bass drivers, while the surround speaker (DS22) provides a rich, enveloping sound with its 20mm tweeter and a single 4” mid-bass. Lastly, the powerful subwoofer (W600/W310) enhances the low-end frequencies, making it ideal for bass-heavy music and explosive movie soundtracks.
Specifications
| Model No. | Driver Unit | Sensitivity | Nominal Impedance | Power Handling | Frequency Response | Dimensions |
|---|---|---|---|---|---|---|
| DP220 (Front Speaker) | 1 x 20mm tweeter + 2×4”mid-bass + 1×8”woofer | 87 dB | 6 Ohms | 20-150W | 40Hz-20KHz | H1020 x W156 x D325 mm |
| DC22 (Center Speaker) | 1 x 20mm tweeter + 2×4”mid-bass | 87 dB | 6 Ohms | 20-100W | 100Hz-20KHz | H140 x W580 x D192 mm |
| DS22 (Surround Speaker) | 1 x 20mm tweeter + 1×4”mid-bass | 86 dB | 6 Ohms | 20-80W | 100Hz-20KHz | H230 x W140 x D192 mm |
| W600/W310 (Subwoofer) | 1 x 10mm woofer | 87 dB | 8 Ohms | 150W RMS | 30Hz-150Hz | H430 x W380 x D450 mm |
