Dry-type Transformer
Inquire NowDescription
The Dry-type Transformer is engineered with advanced epoxy-cast technology, designed to deliver efficient and reliable performance in various electrical applications. This transformer features a robust iron core made from high-quality silicon-steel sheets, ensuring low power consumption and minimal noise. The innovative coil design, including high voltage sectional cylinder coils and low voltage copper foil coils, guarantees optimal fire-resistance, damp-proofing, and excellent cooling capabilities. Enhanced by a thin insulation layer reinforced with silicon-hydride glass-fiber, this transformer offers exceptional voltage withstand strength while maintaining structural integrity. Its vacuum casting process, combined with a modular aluminum alloy casing, provides a durable and aesthetically pleasing solution suitable for both indoor and outdoor installations. Committed to quality, the transformer adheres to ISO standards and utilizes a comprehensive testing protocol to ensure top-tier performance.
Specifications
| Feature | Description |
|---|---|
| Iron Core | Made from fine quality silicon-steel sheets with high magnetic inductivity, featuring a five-stage stepping joint for adjustable champ force and enhanced stability. |
| Coil | High voltage sectional cylinder coils with thin insulation and a high fire-resistance rating; low voltage copper foil coils for effective heat distribution and high efficiency. |
| Insulation Layer | Film resin reinforced with silicon-hydride glass-fiber, capable of withstanding temperatures up to 200℃, minimizing thermal expansion issues. |
| Casing | Modular aluminum alloy casing with IP20 (indoor) or IP23 (outdoor) protection standards, ensuring safety and device integrity. |
| Quality Certification | ISO9001, ISO14001, and ISO18000 certified, ensuring high-quality production processes and environmental protection. |
| Testing Standards | Comprehensive testing including temperature rise, lightning stroke, and partial discharge measurements to ensure compliance with international standards. |
| Environmental Impact | High recovery ratio of up to 90% for disassembled components, adhering to environmental protection laws. |
Additional Information
- Each transformer undergoes rigorous quality management practices to enhance efficiency and reliability.
- The dedicated technical support team is available to assist with customer inquiries and needs.
- Environmental sustainability practices are integrated throughout the manufacturing and disposal processes.
