EAONA brand-AIM-WM5.5-EX
Inquire NowDescription
The WM5.5-EX is an innovative long and thin column sound box designed to deliver exceptional audio clarity, particularly in challenging acoustic environments. Equipped with a direct drive unit, it boasts a wide horizontal coverage angle while maintaining a narrow vertical coverage angle to minimize ceiling reflections. This sound box excels in high-reverberation settings, enhancing the clarity of both musical sounds and human voices. Its sleek design allows for wall mounting without compromising vertical coverage, making it an ideal companion to the W212 low pitch for optimal sound reinforcement.
Specifications
| Sound box type | Two divided-frequency full frequency loudspeaker system for commercial project |
|---|---|
| Frequency response | 80Hz~20KHz (±3dB) |
| Drive unit | High pitch: silk ribbon 40W, Low pitch: 4″ × 2 (100mm), Alto pitch: 5″ × 2 (130mm) |
| Power | 300W (RMS) / 600W (PEAK) |
| Impedance | 8 Ω |
| Sensitivity | 92dB |
| Directivity | 100° Hor × 60° Ver |
| Sound pressure level | Continuous sound pressure level: 110dB, Maximum sound pressure level: 115dB |
| Connections | 2 × NL4 speakon |
| Box | Ultrathin box, 18mm high-quality birch plywood |
| Dimensions | 149 × 698 × 150mm |
| Installation | 4xM8 wall-mounting hidden installation |
| Handling | Integrated embedded handle, single and pairs ergonomic design |
