ECONOMICAL FULL-MOTION TV WALL MOUNT
Inquire NowDescription
The Economical Full-Motion TV Wall Mount (LPA68-443) is designed to accommodate most 23″-55″ flat-panel TVs with a weight capacity of up to 30kg (66lbs). Its full-motion capabilities allow for a tilt range of +3° to -10° and a swivel range of +90° to -90°, providing the flexibility to adjust your TV for optimal viewing from any angle in the room. The integrated cable management system elegantly conceals and organizes cables, ensuring a clean and tidy appearance.
Features:
- Enhanced tilt settings for a better viewing experience.
- Swiveling arms that maximize viewing flexibility, making every seat the best seat in the house.
- Efficient cable management to keep attached cables hidden and organized.
Specifications
| Product Category: | Full-motion TV Wall Mount |
|---|---|
| Rank: | Economy |
| Material: | Steel |
| Metal Sheet Thickness: | Wall Plate THK=2.5mm pickling sheet, VESA Panel THK=1.8mm cold-rolled sheet, Extension Adapter Arm THK=1.2mm cold-rolled sheet |
| Pipe Size: | 30x20x1.2mm Square Steel Tube |
| Surface Finish: | Powder Coating |
| Color: | Fine Texture Black |
| Dimensions: | 382x430x430mm (15″x16.9″x16.9″) |
| Fit Screen Size: | 23″-55″ |
| Fit Curved TV: | Yes |
| Mounting Hole Pattern: | VESA Only |
| VESA Compatible: | 100×100, 100×200, 200×100, 200×200, 300×200, 300×300, 400×200, 400×300, 400×400 |
| Max. VESA: | 400×400 |
| Weight Capacity: | 30kg (66lbs) |
| Strength Tested: | 3 Times Approved |
| Profile: | 60~382mm (2.4″~15″) |
| Tilt Range: | ＋3°～-10° |
| Swivel Range: | +90°~-90° |
| Screen Freely Tilting: | No |
| Installation: | Solid Wall, Single Stud |
| Panel Type: | Detachable Panel |
| Wall Plate Type: | Fixed Wall Plate |
| Direction Indicator: | Yes |
| Cable Management: | Yes |
| Anti-theft: | No |
| Bubble Level: | No |
| Accessory Kit Package: | Compartment Polybag |
Additional Information
Note: This wall mount is designed for easy installation on solid walls and single studs, providing a secure and stable setup for your television.
