Edge milling machine
Inquire NowDescription
The Edge Milling Machine is an advanced piece of equipment designed with cutting-edge technology, making it essential for various industries including pressure vessel manufacturing, boiler production, shipbuilding, electric power generation, and chemical processing. This machine efficiently processes materials, preparing straight edges, bevel edges, and U-type grooves before the welding process, ensuring precision and quality in every operation.
Key advantages of this machine include:
- Sturdy Construction: The machine body is made of welded parts, and after welding, the workpiece undergoes high-temperature backfiring and stress relief to prevent deformation.
- Stability: The guide rail arrangement combines both suspending and base types, significantly improving stability compared to common suspending types and reducing vibrations during operation.
- High-Quality Materials: Crafted from high-quality 45# steel, the guide rails are precisely treated and fixed to enhance durability and precision.
- Efficient Feeding Structure: Each feeding mechanism of the milling head is powered by a frequency motor for consistent performance.
- Workpiece Guard Device: This feature enables fast and convenient positioning, greatly improving operational efficiency.
- Extended Milling Capability: The throat hole at the end beam allows for milling of super-long workpieces by extending to another face.
- Safe Control Panel: The panel is designed with slip-touch cables for safety and aesthetic appeal.
This machine comprises several key components, including the main machine body, press beam, slitting plate and column beam, main shaft box, feeding box, hydraulic system, and electrical control box with operation interface.
Specifications
| Feature | Details |
|---|---|
| Max Length of Workpiece | 6m, 12m, 18m |
| Milling Thickness | 6-80mm |
| Max Depth of Milling | 3mm |
| Milling Angle | 0° – 45° |
| Model of Milling Head | 1TX32 × 2 sets |
| Power of Milling Head Motor | 2 × 5.5KW, Turning speed: 1420 r/min |
| Suitable Diameter of Milling Cutter | D = 200 mm |
| Turning Speed of Main Shaft | 80 – 400 r/min |
| Expansion Length of Main Shaft | 63 mm |
| Milling Forward Speed | 0.2 m/min – 0.6 m/min |
| Forward Motor Power | 1.5 kw |
| Quick Forward and Return Speed of Milling | V=1.2 m/min |
| Power of Hydraulic System | 5.5 kw |
| Pressure of Hydraulic System | ≤ 3.5 Mpa |
Additional Information
The Edge Milling Machine is an essential tool for industries requiring precision edge preparation before welding. Its robust design and advanced technology ensure high-quality performance and efficiency in various applications.
