EDM350ZNC
Inquire NowDescription
The EDM350ZNC is a state-of-the-art EDM sinker machine designed for cavity forming, utilizing conductive materials such as copper, graphite, and steel as electrodes. This machine excels in processing complex parts and molds with high precision, making it an essential tool in metal processing and mold-making workshops. With over 20 years of experience and a robust production facility of 56,000 m², the company behind the EDM350ZNC boasts advanced technology, including a 6S management system and over 47 patents. The machine’s design ensures reliability and efficiency, providing features such as a steady safety device, optical sensors, and a high-quality imported oil pump, all tailored for exceptional performance in various industrial applications.
Specifications
| Parameters | Unit | EDM350ZNC |
|---|---|---|
| Working Tank (L x W x H) | mm | 900 x 550 x 350 |
| Table Size (L x W) | mm | 600 x 350 |
| Travel Size X | mm | 350 |
| Travel Size Y | mm | 250 |
| Spindle Travel Z | mm | 180 |
| Auxiliary Travel Z | mm | 180 |
| Max. Table Load (Workpiece weight) | kg | 800 |
| Max. Spindle Hold (Electrode weight) | kg | 120 |
| Oil Tank | L | 470 |
| Control Method | DC (Japan SANYO) | |
| Machine Dimension (L x W x H) | mm | 1500 x 1500 x 2200 |
| Machine Weight | kg | 1300 |
Additional Information
The EDM350ZNC features a robust construction designed for longevity and high precision, including:
- Japan SANYO FC servo motor for reliable operation.
- Optical sensors and safety devices ensure maximum operational safety.
- High rigidity and precision through V slide design and HT300 aging treatment casting.
- Advanced lubrication system that ensures cleanliness and efficiency.
- Capability of processing copper, graphite, and steel for specialized applications.
