electric start open or silent type diesel generator

Inquire Now

Description

The electric start open or silent type diesel generator offers reliable power solutions for various applications, ensuring smooth operation in both residential and commercial settings. Designed with versatility in mind, this generator can perform optimally in various environments—whether you require silent operation for noise-sensitive areas or an open-style generator for robust performance. The innovative design includes a powerful engine and efficient alternator, providing a dependable power source whenever you need it.

Features include:

  • Brand-new engine with start motor
  • Brushless alternator with single bearing and IP23 rating
  • Auto control panel equipped with an LCD display
  • Engine-mounted battery-charging alternator
  • Circuit breaker and exhaust silencer included
  • Copper radiator designed for 40ºC ambient temperature
  • Anti-vibration pads for stable operation
  • Skid-mounted bottom fuel tank with 8-hour capacity
  • Emergency stop button for enhanced safety
  • Optional features: Soundproof casing, ATS, AMF panel, trailer, parallel system

Specifications

Generator Model EPS-CU24
Frequency 50Hz / 60Hz
Speed 1500rpm / 1800rpm
Prime Power 30kVA / 24kW / 33kVA / 24kW
Standby Power 33kVA / 26kW / 36kVA / 29kW
Type Open/Silent/Trailer
Voltage 110V – 440V
Phase 3 phase, 4 wires
Power Factor 0.8 lagged
Engine YANGDONG 4102D
Alternator Poweronly/Stamford/Leorysomer
Controller ComAp/Smartgen/Deepsea

Additional Information

This generator is equipped with advanced features to ensure optimal performance and user safety. It is perfect for both prime and standby applications. The warranty terms include up to 1000 hours for prime use and 500 hours for standby use, providing you peace of mind with your investment.
