Description
Introducing the Electric Utility Vehicle GLT3023, a state-of-the-art vehicle designed for efficiency and performance in various utility applications. With a focus on quality, this vehicle is perfect for transporting goods or passengers across diverse terrains. Its robust steel framework and fiberglass body ensure durability while maintaining a lightweight structure. The GLT3023 is powered by a reliable 48V motor, offering a smooth driving experience with a maximum speed of 25 km/h. Ideal for short-distance travel, it features a generous range of 80 km on a single charge, making it a practical choice for utility tasks.
Specifications
| Feature | Details |
|---|---|
| Rated Passengers | 2 persons |
| Dimensions (L x W x H) | 4,030 x 1,430 x 2,550 mm |
| Wheelbase | 2,080 mm |
| Ground Clearance | 220 mm |
| Net Weight | 1,200 kg |
| Distance per Charge (Full Load) | 80 km |
| Brake Distance | 4.5 m |
| Max. Running Speed | 25 km/h |
| Min. Turning Diameter | 12 m |
| Max. Climbing Capability (Full Load) | 20% |
| Rated Loading Capacity | 0.8 T |
| Body | Steel framework + Fiberglass body |
| Storage Battery | 48V, 225Ah |
| Motor | 4 kW, 48V |
| Charger | 48V, 25A |
| Controller | Curtis Sepex1209B-6402 |
| Steering System | Ball bearing, automatic compensating function |
| Wheel Size | 155/80 R12 |
| Front Windshield | Tempered Glass |
| Seats | High elasticity water-proof big seats |
| Conveyance | Qty/40′ FCL: 6 pcs, Qty/40′ HQ: 6 pcs |
Additional Information
- Customizable options available, including variants for 1.5T and 2T loading capacities.
