End suction pump
Inquire NowDescription
The End Suction Pump is designed to efficiently handle a variety of applications, making it an essential tool for industries requiring reliable fluid transfer. This robust pump excels in cooling water systems, water supply and distribution, fire protection, drainage, irrigation, and general industrial services. With a capacity of up to 4000 USGPM (900 m3/h) and a head of up to 460 feet (140 m), it is capable of performing under demanding conditions. The pump operates at speeds of 2900/1450 rpm and 3500/1750 rpm, ensuring versatility and adaptability to different operational needs.
Specifications
| Attribute | Details |
|---|---|
| Capacity | Up to 4000 USGPM (900 m3/h) |
| Head | Up to 460 feet (140 m) |
| Temperature | Up to 200°F (105°C) |
| Speed | 2900/1450 rpm, 3500/1750 rpm |
| Casing Material | Cast iron, Ductile cast iron, Stainless steel |
| Impeller Material | Cast iron, Stainless steel, Duplex stainless steel, Bronze |
| Shaft Material | Stainless steel |
| Wear Ring Material | Cast iron, Stainless steel, Bronze |
Additional Information
With its durable construction and high performance, the End Suction Pump is an excellent choice for various industrial applications. Ensure regular maintenance for optimal performance and longevity.
