EP-6800-HA-UD/20~35
Inquire Now
MV Station Integrated outdoor inverter, transformer, and Communication& monitoring system
1500V large capacity centralized grid connection, low initial investment cost
?Adapt to various harsh environments such as high temperature, high humidity, high dust, salt spray, etc
-
MV Station Integrated outdoor inverter, transformer, and Communication& monitoring system
-
1500V large capacity centralized grid connection, low initial investment cost
-
Adapt to various harsh environments such as high temperature, high humidity, high dust, salt spray, etc
Technical Parameters
Input (DC)
| Max. PV input voltage | 1500V |
| Max. input current | 4075A*2 |
| MPP voltage range for nominal power | 900~1300V |
| Number of MPPT trackers | 2 |
| Number of DC inputs | (16~22)*2 |
Output (AC)
| Rated AC output power | 2*3400kVA@45℃ |
| Max. AC output power | 2*3594kVA@25℃ |
| AC voltage range | 20~35kV |
| Rated grid frequency/range | 50 Hz/ 45~55 Hz, 60Hz/ 55~65Hz |
| Output current harmonic (at nominal power） | < 3 % |
| DC current injection | < 0.5% In |
| Power factor at nominal power/range | >0.99/ 0.8 lagging to 0.8 leading |
Protection
| DC input protection | Load break switch+fuse |
| AC output protection | Circuit breaker |
| AC MV output protection | Circuit breaker |
| Overvoltage protection | DC Type II / AC Type II |
| Leakage current monitoring | Yes |
| Grid monitoring/Ground fault monitoring | Yes/Yes |
| Insulation monitoring | Yes |
| Overheat protection | Yes |
| Night SVG function | Optional |
| Anti-PID function | Optional |
Efficiency
| Max. efficiency | 99.00% |
| EU efficiency | 98.70% |
Transformer
| Transformer Rated power | 6800kVA |
| Transformer Max. power | 7188 kVA |
| LV / MV Voltage | 0.63-0.63/20~35kV |
| Transformer Vector | Dy11y11 |
| Transformer cooling type | ONAN (Oil Natural Air Natural) |
General date
| Weight | 25t |
| Protection level | Inverter:IP65, Others:IP54 |
| Auxiliary power supply | Standard:5kVA, Optional: max.40kVA |
| Temperature | -30~+60℃ (>45℃ derating) |
| Allowed humidity (non condensing) | 0 – 95 % |
| Cooling mode | Temperature controlled forced air cooling |
| Max.operating altitude | 2000m (standard) / > 2000m (optional) |
| Display | LCD |
| Communication port | RS485/Ethernet |
