Quick Details
Type: Centrifugal Fan,Water Mist Fan Electric Current Type: AC Blade Material: Aluminum Mounting: Wall Fan Place of Origin: Guangdong, China (Mainland) Brand Name: SOFFNET Model Number: FB6-65;FB6-75 Power: 240-280 Voltage: 220 Air Volume: 210-290 Speed: 1420 Material: Metal Installation: Pedestal Power Source: Electric Voltage (V): 220 Power (W): 240-280
Packaging & Delivery
Packaging Details: Inner Packing:Plastic Bag & Foam Outer Packing:Carton Box CKD packing
Delivery Detail: 30 days
Specifications
1)Durable Fan Motor
2)Centrigual Automization without nozzle & filter
3)Low Usage Cost
Model Diameter Use Area Temperature Drop Power Speed Air volume Noise
mm m2 C w r/min m3/min dB(A)
FB6-65 650 35 4-6 240 1420 210 68
FB6-75 750 40 4-6 280 1420 290 75
1.Durable Fan Motor
Full cooling temperature system,motor with long service life
Whole unit operate just like a fan with low noise level from air delivery
2.Centrifugal Automoization
Without nozzle,incure additional maintenance cost
Without filter,using misting disck under high speed to bring misting mote size 20-25 micron
3.Low Usage Cost
Just plug in the power socket and with water supply the units start cooling at the lowest cost
Water tank:35L,maximal misting volume:2.5-2.8L/H,continuous misting running time:8-10H
Applications
Factory and warehouse
BBQ areas, open air cafe and commercial applications
Open-air resaturants, garden parties, green houses, liverstock farms
Can be fitted to pedestaland mancooler recirculating fans up to 630mm diameter
