Film Blowing Machine
Inquire NowDescription
The Film Blowing Machine is an advanced piece of equipment specifically designed for producing high-quality plastic films from materials such as LDPE, HDPE, and LLDPE. This versatile machine is ideal for a wide range of applications, including packaging for food, fruits, clothing, textiles, daily necessities, and industrial products. With its innovative rolling system utilizing torque motors, it ensures constant roll-up tension, achieving exceptional film flatness, compaction, and steadiness. The frequency speed regulation enhances operational efficiency by allowing smooth and steady speed changes, while also being more energy-efficient and easier to maintain compared to traditional systems.
Constructed with a durable screw and barrel made from 38CrMoAIA with double mixing capability, this machine promises long service life and increased productivity. Its rotary die head is engineered to produce films with a consistent thickness and smooth surface, while the polished die head path reduces resistance and facilitates easy cleaning. The auxiliary machinery features an aesthetically pleasing design coupled with user-friendly operation, and height adjustment equipment ensures optimal production conditions for various film specifications.
Specifications
| No. | Item | Technical Parameter |
|---|---|---|
| 1 | Model | SJZD－45 |
| 2 | Max. Extruding Capacity | 30 kg/h |
| 3 | Main Driving Power | 15 kW |
| 4 | Filter Changing Method | Durable filter (patent) |
| 5 | Heating Power | 15 kW |
| 6 | Single-face Thickness | 0.005 – 0.12 mm |
| 7 | Max. Folded Diameter | 700 mm |
| 8 | Tractor Driving Power | 0.75 kW |
| 9 | Winding Motor | 6 N.m |
| 10 | Installation Power | 33 kW |
| 11 | Overall Dimension (L×W×H) | 5.5 m × 2 m × 3.5 m |
| 12 | Weight | 1200 kg |
Additional Information
Design and specification are subject to change without notice. All rights reserved, imitation is not permitted.
