FIN TYPE EVAPORATOR
Inquire NowDescription
The Fin Type Evaporator is an essential component designed for effective heat transfer in various cooling applications. Crafted with high-quality raw materials, it ensures optimal performance and reliability. The evaporator features aluminum tubes and fins, providing excellent thermal conductivity while maintaining a lightweight structure. The innovative design caters to a range of processing capacities, making it suitable for various industrial requirements.
This evaporator not only meets stringent technical standards but also offers versatility in its installation styles, including diagonal-inserting and pull-expanding styles. Its robust construction guarantees longevity and efficiency in cooling systems.
Specifications
| Type | Specification | Processing Capacity |
|---|---|---|
| Diagonal-inserting style | 50*19.05*N (≤29) |
Fin pitch: 4mm~6.5mm Expanding length ≤ 770mm Max. number of expanding elbow: 14.5 holes |
| 60*19.05*N (≤29) |
Fin pitch: 4mm~6.5mm Expanding length ≤ 770mm Max. number of expanding elbow: 14.5 holes |
|
| Pull-expanding style | 40*28 | Single-hole |
| 52*28 (Double holes) |
Double holes Center distance: 25mm Bending radius: R15 |
|
| 60*28 (Double holes) |
Double holes Center distance: 25mm Bending radius: R15 |
|
| 75*25 (Three holes) |
Double holes Center distance: 25mm Bending radius: R15 |
|
| 35*22 (Double holes) |
Double holes Center distance: 20mm Bending radius: R12.5 |
Additional Information
- Raw Materials:
- Aluminum tube: Ø8.0*0.65~1mm
- Aluminum fin: Bare fin thickness T= 0.12~0.2mm
- Side plate: Aluminum plate T= 0.7~1.5mm
- Technical Standards: The evaporator adheres to industry-specific standards for thermal efficiency and durability.
