Description
The FK10 series VCB pilot micro switch auxiliary contact AUS auxiliary switch is designed for high-voltage (HV) applications, facilitating the operation of switching mechanisms, interlocking, and controlling signal circuits. Suitable for use in HV switchgears, this versatile switch can function as either a transfer switch or a cubicle switch, making it a reliable choice for various industrial settings.
Engineered to meet demanding operational requirements, the FK10 series ensures efficient performance in controlling electrical loads with a range of voltage and current ratings. Its durable construction and precise actuation features make it essential for anyone looking to enhance their HV electrical systems.
Specifications
| Attribute | Details |
|---|---|
| Electrical Load | AC 80V, 6A; AC 220V, 10A; AC 240V, 6A; AC 415V, 4A; AC 500V, 3A; AC 660V, 2A |
| Rated Working Voltage | AC 660V |
| Rated Working Current | 0.4A |
| Rated Isolation Voltage | 690V |
| Rated Frequency | 50 Hz |
| Rated Current | 15 A |
Operative Parameters
| Actuating Force | Contact Pressure (NC contact) | Actuating Length | Electrode Travel | Constriction Resistance | Delay Length |
|---|---|---|---|---|---|
| ≤16N | 0.55 N | 4 mm | 3 mm | 50 mΩ | 0.3 mm |
Structure
- The turning angle of the series FK10 can be adjusted between 60° to 120° based on specific requirements.
- Available in straight type and horizontal type configurations, the FK10 series is designed for versatile assembly options, including horizontal structures and straight delay contacts.
