Flat Sheet Roof Construction Machine
Inquire NowDescription
The Bh Steel Flat Sheet Roll Forming Machine is engineered for precision and efficiency in the construction industry. This robust machine is designed to create flat sheets for roofing applications, combining advanced technology with practical functionality. With a strong reputation for quality and reliability, this machine is built to meet the rigorous demands of various construction projects. Our professional engineering team is available to provide tailored designs and overseas technical guidance, ensuring that the machine meets your specific requirements. The factory’s commitment to quality control and safety standards guarantees a long operational life at a reasonable price, backed by timely after-sales support.
Specifications
| Feature | Details |
|---|---|
| Production Name | Bh Steel Flat Sheet Roll Forming Machine |
| De-Coiler | Passively De-Coiling |
| Load-Bearing of De-Coiler | 5 T |
| Frame of Machine | Welded with 350H Beam Steel |
| Thickness of Wallboard | 16 mm |
| Guide Feeding Way of Forming | Side Direction Roller Type |
| Forming Machine Type | Wallboard and Chain Driver |
| Diameter of Shaft | ￠70mm |
| Chain | 16A Single Row |
| Motor Power of Forming Machine | 5.5KW |
| Hydraulic Station Motor | 3.0 KW |
| Hydraulic Station Pressure | 8-12Mpa |
| Voltage | 380V, 50Hz, 3 Phases |
| Hydraulic Station Oil Pump | Gear Pump |
| Electrical Control System | Computer Adopts PLC |
| Line Speed of Forming Machine | 10-12m/min |
| Steps of Forming Machine | 18 Steps |
| Roller Material | Superior 45# Steel Forging |
| Thickness of Chrome Plated on Roller | 0.05mm |
| Cutting Type | Hydroforming Shear |
| Cutting Blade Material | Cr12 |
| Cutting Blade Heat Treatment | HRC58o-60 |
| Rolling Thickness | 0.3-0.8 mm |
| Feeding Width | 1000mm |
| Effective Width | 900mm |
Additional Information
This machine is not only efficient but also cost-effective as it produces its own accessories, reducing the need for external purchases. It complies with all safety export standards, making it a preferred choice for many large companies globally. The machine’s longevity and superior craftsmanship make it an excellent investment for any construction business.
