Forklift-LG160DT
Inquire Now–
|
Model
|
LG160DT
|
|
|
Power Type
|
Diesel
|
|
|
Load Capacity
|
16000 kg
|
|
|
Load Center
|
600 mm
|
|
|
Max. Lifting Height
|
4000 mm
|
|
|
Free Lifting Height
|
150 mm
|
|
|
Fork Dimension
|
1800X200X105 mm
|
|
|
Tilling Angles (Forward/Backward)
|
6°/ 12°
|
|
|
Fork Overhang
|
979 mm
|
|
|
Rear Overhang
|
1231 mm
|
|
|
|
Overall Length
|
7500 mm
|
|
Overall Width
|
2776 mm
|
|
|
Overall Height
(Mast Lowered and Upright) |
3925 mm
|
|
|
Safety Rack Height
|
3445 mm
|
|
|
Min. Turning Radius
|
5800 mm
|
|
|
Min.Intersecting Aisle
|
5230 mm
|
|
|
Max.Travel Speed (with load/without load)
|
25/25 Km/h
|
|
|
Max. Lifting Speed(with load/without load)
|
400/300 mm/s
|
|
|
Max Gradeability(with load/without load)
|
20%
|
|
|
Total weight
|
19000 kg
|
|
|
Tire
|
Front
|
12.00-24-18PR
|
|
Rear
|
||
|
Tread
|
Front
|
2060 mm
|
|
Rear
|
2120 mm
|
|
|
Wheel Base
|
3800 mm
|
|
|
Min. Under-clearance
|
Bottom of Mast
|
330 mm
|
|
Frame
|
358 mm
|
|
|
Engine
|
Modle
|
YuChai YC6A175Z-T10
|
|
Rate Power
|
128 kw
|
|
|
Rate Torque
|
670/1500-1800
|
|
|
Number of Cylinders
|
6
|
|
|
Displacement
|
7.252 cm3
|
|
|
Fuel Tank Capacity
|
350 ltr
|
|
