FY20 dumpers/tippers
Inquire NowDescription
The FY20 dumpers/tippers are robust and efficient vehicles designed for heavy-duty tasks in construction and agricultural settings. Manufactured in Jiangsu, China, these tippers are built to handle a rated load of up to 2000 kg, making them ideal for transporting materials. With a rated bucket capacity of 1.0 m³ and a dumping height of 390 mm, they ensure optimal performance in loading and unloading operations. The FY20 model stands out with its three forward gears and one reverse gear, offering versatile speed options of up to 22 km/h.
Specifications
| Item | FY20 |
|---|---|
| Rated load (kg) | 2000 |
| Rated bucket capacity (m³) | 1.0 |
| Dumping height (mm) | 390 |
| Max climbing gradient (°) | 21 |
| Bucket width (mm) | 1580 |
| Travel speed (km/h) | Forward gear I: 9, Forward gear II: 9, Forward gear III: 22, Reverse gear: 7.5 |
| Min turning radius (mm) | 4500 |
| Overall dimensions (mm) | 4000 * 1600 * 2670 |
| Wheelbase (mm) | 2090 |
| Tread (mm) | 1400 |
| Minimum ground clearance (mm) | 200 |
| The weight of machine (kg) | 1890 |
| Engine Model | 2105 |
| Rated power (kw) | 24 |
| Rated speed (r/min) | 2200 |
| Tipping system | Electric starting: Yes |
| Drive | 4 wheel drive |
Additional Information
- Packaging: Standard exporting packing
- Delivery Time: 15 days after receiving payment
