galvanised c z channel forming machine roll forming upright profile machine
Inquire NowDescription
The Galvanised C Z Channel Forming Machine is an advanced roll forming upright profile machine designed for efficient manufacturing of C and Z purlins. This state-of-the-art equipment features a manual uncoiler, guiding platform, and a robust PLC control system, ensuring precise and high-quality production. The machine is capable of producing profiles with a width range of 80-300mm and is built to handle feeding thicknesses from 1.5mm to 3.0mm. Its durable construction and hydraulic control system make it ideal for use in various industrial applications, including factory buildings, warehouses, and easy steel building manufacturing. The elegant design not only enhances functionality but also provides a visually appealing addition to any manufacturing setup.
Specifications
| Parameter | Details |
|---|---|
| Configurations | Manual Uncoiler, Guiding Platform, 9 Shaft Strip Leveler, Main Machine Of Roll Forming, Hydraulic Motor, Pre-Punching Device, Pre-Cutting Device, Hydraulic Station, PLC Control, Supporter Table |
| Control System | PLC Inverter Encoder Touch Screen |
| Main Frame | 400mm H-Beam |
| Total Power | 22 kW |
| Power Supply | 380V, 3-Phase, 50Hz |
| Forming Speed | 12-24m/min |
| Roll Station | 18 stands |
| Roller Diameter | 80mm |
| Effective Width | 80-300mm |
| Feeding Thickness | 1.5-3.0mm |
| Backboard Thickness | 20mm |
| Cutter Standard | GCr12 |
| Roller Standard | Gcr15# |
| Overall Size | About 8500×1000×1400mm |
| Total Weight | About 10T |
Additional Information
Warranty: 12 months limited warranty. During warranty: parts are free but buyer pays for the shipping fee.
Terms of Payment: 30% of the total contract value paid by T/T as a down payment. The remaining 70% to be paid by T/T after inspection by the buyer in the seller’s factory before delivery.
Delivery: 30 days after receipt of advance payment.
Service: Technicians will be sent to the buyer’s country for installation and operation training, with costs covered by the buyer.
