galvanized steel sheet corrugated roll forming machine 1250mm roofing roll forming machine
Inquire NowDescription
The galvanized steel sheet corrugated roll forming machine is a cutting-edge solution designed for the efficient production of roofing and wall panels. With a maximum forming speed of 10-15 m/min, this machine is easy to operate and provides permanent support for remote services. Engineered with precision, it utilizes pre-painted and galvanized steel coils to create durable and high-quality roofing solutions.
Specifications
| Product Name | Steel roof & wall forming machine |
|---|---|
| Material | Pre-painted & galvanized steel coil |
| Thickness (mm) | 0.3-0.7 mm |
| Tield Stress (Mpa) | Q235-345 |
| Max. Forming Speed (m/min) | 10-15 m/min |
| Roller Material | #45 steel with hard chrome treatment |
| Roller Driven Type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic System Pressure (Mpa) | 12 |
| Main Motor Power (KW) | 4 |
| Hydraulic Station Motor Power | 3 |
| Dimension (L*W*H) | about 8500 * 1500 * 1500 mm |
| Weight (KG) | about 6000 |
Additional Information
Our service includes pre-sales consultations, on-purchase service, and 24/7 after-sales support. We provide technical guidance, a one-year warranty period, and spare parts at cost after the warranty period. Feedback collection and long-term technical assistance are also part of our commitment to customer satisfaction.
