Gasoline Generator 3.5/4.0/5.0/6.0/7.0kw
Inquire NowGasoline Generator 3.5/4.0/5.0/6.0/7.0kw
| GENERATOR | Generator Model | PG4500BL/E | PG5000BL/E | PG5500BL/E | PG6500BL/E | PG8000BL/E | PG10000BL/E |
| Type | Brush type, Single-phase | Brush type, Single-phase | Brush type, Single-phase | Brush type, Single-phase | Brush type, Single-phase | Brush type, Single-phase | |
| Rated Voltage | 110V、120V、220V、230V、240V、110V/220V、120V/240V | ||||||
| Rated Frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | |
| Rated output | 3.5KW/3.7KW | 4.0KW/4.5KW | 4.0KW/4.5KW | 5.0KW/5.5KW | 6.0KW/6.5KW | 7.0KW/7.5KW | |
| Max. Output | 3.8KW/4.0KW | 4.5KW/5.0KW | 4.5KW/5.0KW | 5.5KW/6.5KW | 6.5KW/7.0KW | 7.5KW/8.0KW | |
| Power Factor | COS φ=0.83 | COS φ=0.83 | COS φ=0.83 | COS φ=0.83 | COS φ=0.83 | COS φ=0.85 | |
| ENGINE | Engine Model | PW270 | PW306 | PW390 | PW390 | PW420 | PW460 |
| Displacement | 270cc | 306cc | 389cc | 389cc | 420cc | 460cc | |
| Net Power | 5.2KW/3600rpm | 6.5KW/3600rpm | 8.3KW/3600rpm | 8.3KW/3600rpm | 8.8KW/3600rpm | 10.5KW/3600rpm | |
| Bore×Stroke | 77mm×58mm | 82mm×58mm | 88mm×64mm | 88mm×64mm | 90mm×66mm | 92mm×69mm | |
| Fuel Type | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | |
| Fuel Tank Capacity | 25L | 25L | 25L | 25L | 25L | 25L | |
| Oil type | SF or Higher Grade | SF or Higher Grade | SF or Higher Grade | SF or Higher Grade | SF or Higher Grade | SF or Higher Grade | |
| Oil Capacity | 1.1L | 1.1L | 1.1L | 1.1L | 1.1L | 1.1L | |
| Noise | 72dB | 72dB | 72dB | 72dB | 72dB | 72dB | |
| Lubrication | Splash | Splash | Splash | Splash | Splash | Splash | |
| Starting System | Recoil start/Electric-start | Recoil start/Electric-start | Recoil start/Electric-start | Recoil start/Electric-start | Recoil start/Electric-start | Recoil start/Electric-start | |
| Chock Type | Manual Lever/Automatic lever | Manual Lever/Automatic lever | Manual Lever/Automatic lever | Manual Lever/Automatic lever | Manual Lever/Automatic lever | Manual Lever/Automatic lever | |
| PACKAGE DIMENSION |
Dry Weight | 65.2Kg/75.2Kg | 69.5Kg/79.5Kg | 71.6Kg/81.6Kg | 77.0Kg/87.0Kg | 79.5Kg/89.5Kg | 82.5Kg/92.5Kg |
| Dimensions（LxWxH） | 700 mm× 535 mm× 575mm/700 mm× 535 mm× 565mm | ||||||
| 20FT/40FT/40HQ | 127/272/272 | 127/272/272 | 127/272/272 | 127/272/272 | 127/272/272 | 127/272/272 | |
