GCBC-II Briquette Press
Inquire NowDescription
This briquette machine, the GCBC-II, is expertly designed to produce hexagon-shaped wood or charcoal briquettes featuring a central hole for optimal airflow during burning. This design not only enhances burning efficiency but also caters to various materials such as sawdust, wood branches, wood residues, and biomass wastes. The GCBC series is a high-end briquetting solution, refined through six years of research and development, emphasizing both aesthetics and structural integrity. Notably, the inner former remains unchanged until the input capacity surpasses 1000 tons, showcasing its durability and efficiency.
Specifications
Model | GCBC-II |
---|---|
Output capacity (kg/h) | 300-350 |
Motor Power (kw) | 18 |
Electric heater (kw) | 2.2kw×2 |
Life of the inner former | 1-2 years |
Size of briquettes | Dia. 60mm * L. 500mm |
Size of inside hole | Dia. 16mm |
Density of briquettes | 1.3 g/cm³ |
Weight (kg) | 1000 |
Overall dimension (mm) | 2000 * 600 * 1700 |
