glazed tile roof sheet roll forming machine
Inquire NowDescription
The Glazed Tile Roof Sheet Roll Forming Machine is an essential piece of equipment for manufacturers looking to produce high-quality, durable roofing materials. This machine is designed to form glazed tile roof sheets with precision and efficiency, catering to the evolving demands of the construction industry. With its robust construction and advanced technology, it guarantees longevity and superior performance. The machine is capable of handling various material thicknesses, making it versatile for different projects.
Specifications
| Attribute | Details |
|---|---|
| Material Thickness Range | 0.2 – 0.8 mm |
| Main Motor Power | 5.5 kW |
| Hydraulic Station Power | 4 kW |
| Speed | 3 m/min (including punching and cutting) |
| Quantity of Rollers | 14 |
| Material of Rollers | 45# with chromed |
| Shaft Material & Diameter | ￠75 mm, 45# forged steel |
| Body Material | 350H |
| Tolerance | 10 m ± 1.5 mm |
| Way of Drive | Chain / gearbox |
| Control System | PLC |
| Cutter Blade Material | Cr12 mould steel with quenched treatment 58-62℃ |
| Voltage | 380V / 3 phase / 50 Hz |
| Machine Size | Length: 8-9 m |
| Weight | 10 ton |
Additional Information
- Efficient for large-scale production.
- Suitable for various roofing applications.
- Designed with durability in mind.
