GPON ONU 2GE with WIFI
Inquire NowDescription
The GPON ONU 2GE with WiFi is a versatile and compact device designed for seamless integration into any Fiber To The Home (FTTH) network. This ONU (Optical Network Unit) supports GPON and EPON, making it compatible with various FTTx PON technologies. Its plug-and-play capabilities ensure easy setup, while its robust features, such as auto detection, configuration, and firmware upgrading, make it the ideal solution for high-speed internet connectivity.
Featuring advanced diagnostic monitoring and remote disabling of fiber optics, the device is also compatible with leading OLTs from Huawei, ZTE, and Fiberhome. With full-speed 1G non-blocking switching and a 2048 MAC address table, the GPON ONU guarantees reliable performance and extensive connectivity options. The integrated Quality of Service (QoS), including four-level priority queues, ensures optimal traffic management for a superior user experience.
Specifications
| Technical Items | Descriptions |
|---|---|
| Fiber Port | 1 GPON, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Fiber Interface | SC/PC |
| RX Sensitivity | <-28dBm (1490nm) |
| WLAN | IEEE802.11b/g, 300Mbps, built-in antenna |
| LAN | 1*10/100/1000Mbps + 1*10/100Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
| DC Power | 12V 1A, external AC-DC power adapter |
| Button | Reset, power, WIFI |
| Power | ≤10W |
| Operation | Working temperature: -5~+55℃, working humidity: 10~90% (non-condensation) |
| Storage | Storage temperature: -30~+60℃, storage humidity: 10~90% (non-condensation) |
| Dimension | 130*107*31mm (length*width*height) |
| Net Weight | ≤0.2Kg |
Additional Information
- Designed for FTTH (Fiber To The Home) networks.
- Supports auto polarity detection of Ethernet ports (AUTO MDIX).
- Integrated port monitoring, mirroring, rate limiting, and service level agreements (SLA).
