GSV20 Monoblock Directional Control Valve
Inquire NowDescription
The GSV20 Monoblock Directional Control Valve is engineered for precision and reliability in fluid management. With a maximum operating pressure of 25 bar, this valve accommodates high flow rates, making it ideal for a diverse range of industrial applications. The spool features smoothly polished surfaces, ensuring precise control over fluid flow. This hydraulic pilot-operated valve is designed with convenience in mind, incorporating an overload valve and charging valve for easy maintenance. Available in four positions, it allows the cylinder to float, providing flexibility in operation. The GSV20 also offers a wide selection of spool functions, with a loop type configured for serial-parallel connection and spring return location mode.
Specifications
| Attribute | Details |
|---|---|
| Maximum Operating Pressure | 25 bar |
| Spool Functionality | Wide choice available |
| Connection Type | Serial-Parallel |
| Location Mode | Spring Return |
| Maintenance Features | Overload valve and charging valve |
Additional Information
No additional information available.
