Description
The GW50Q-3/GW70Q-3 is a robust and efficient vehicle designed for versatile utility. With its compact dimensions of 1550 x 660 x 880 mm, it is ideal for navigating tight spaces while offering impressive performance. The vehicle features a sturdy spoke/alloy rim type and a dry weight of 68 kg, ensuring durability and stability on various terrains. Its maximum loading capacity of 75 kg makes it suitable for transporting goods or equipment.
Powered by a single-cylinder, air-cooled, four-stroke engine model 1P39FMB/1P47FMD, the GW50Q-3/GW70Q-3 delivers a powerful performance with a displacement of 72 ml and a maximum speed of 45 km/h. The economical fuel consumption of just 1.6 l/100 km enhances its efficiency for prolonged use. Additionally, the vehicle features a comfortable ground clearance of 150 mm, allowing for smooth rides over uneven surfaces.
Specifications
| Attribute | Details |
|---|---|
| Dimensions (L×W×H) | 1550 x 660 x 880 mm |
| Wheel Base | 950 mm |
| Ground Clearance | 150 mm |
| Rim Type | Spoke / Alloy |
| Dry Weight | 68 kg |
| Front Tyre Size and Pressure | 2.50-14 / 175 KPa |
| Rear Tyre Size and Pressure | 2.50-14 / 200 KPa |
| Front Brake | Drum |
| Rear Brake | Drum |
| Max Loading Capacity | 75 kg |
| Fuel Tank Capacity | N/A |
| Max Speed | 45 km/h |
| Fuel Consumption | 1.6 l/100 km |
| Brake Performance | ≤ 7 m / 30 km/h |
| Max Fork Advancing Angle | 10° |
| Max Noise Level | 80 dB(A) |
| Engine Model | 1P39FMB/1P47FMD (Four Stroke) |
| Engine Type | Single-cylinder, air-cooled, four-stroke |
| Bore x Stroke | 47 x 41.4 mm |
| Displacement | 72 ml |
| Compression Ratio | 7.0:1 |
| Power | 3.6 kW / 7500 r/min |
| Max Torque | 5.6 N.m / 5000 r/min |
| Starting Mode | Electric Start / Kick Start |
| Ignition Mode | CDI Electronic Ignition |
