H.265 DVB-T2 set top box HDTR875P4
Inquire NowDescription
The H.265 DVB-T2 Set Top Box HDTR875P4 is your gateway to an exceptional viewing experience. Fully compliant with DVB-T2 and DVB-T standards, this advanced set-top box supports a range of video and audio formats, including MEPG-4 AVC and H.265, ensuring that you can enjoy your favorite content in stunning high definition. With multiple bandwidth options (6M, 7M, and 8M) and support for various modulations such as 64QAM and QPSK, it guarantees compatibility with a wide array of broadcast signals.
This versatile device enables video decoding and output of 1080p, 1080i, and 720p resolutions, along with analog video output for both PAL and NTSC systems. Features like USB 2.0 support for upgrades, PVR functionality, and time shifting make it a perfect fit for modern viewing habits, while parental control, teletext, and subtitle support enhance usability. With a sleek design and user-friendly interface, the HDTR875P4 also includes an electronic program guide (EPG) and a program editor for customization.
Specifications
| Attribute | Details |
|---|---|
| CPU and Memory | |
| CPU | Mstart 7T10 |
| DDR2 | 512Mbit (64MByte) |
| Flash | 32Mbit (4MByte) |
| Tuner | |
| Tuner | R836 & MXL608 |
| Connector Type | RF In/ANT In (IEC-Female), Loop, SCART, HDMI |
| Input Frequency | (UHF) 470∽866MHz, (VHF) 170∽231MHz |
| Bandwidth | 6, 7, 8MHz |
| Signal Input Level | -78∽-20dBm |
| Input Impedance | 75 Ohm |
| Active Antenna | 5V (On/Off), Imax=100mA |
| Demodulation Scheme | QPSK, 16-QAM, 64-QAM, 256-QAM |
| Software Function | |
| OS | ECOS |
| EPG | Supports 7 days Electronic Program Guide |
| Video Decoding | MPEG1, MPEG2, MPEG4, H264, VC-1, MOTION JPEG, MPG, MP4, H.265 |
| Video Format | avi, mp4, mkv, mov, dat, flv, mpg, vob, 3gp, ts |
| Audio Decoding | MPEG-1/2/3/4, wma |
| Audio Format | mp3, wma, agg |
| Picture Format | JPEG, BMP, PNG |
| Video Resolution | 480i, 480P, 576i, 576P, 720P, 1080i, 1080P |
| Video Aspect Ratio | 4:3(LB/SCAN), 16:9(LB/FIT) |
| Analog Video System | PAL, NTSC, SECAM |
| OSD Language | Nine kinds of language |
| LCN Sort | Supports Logic Channel Number |
| Teletext | VBI insertion for Teletext, CC and WSS |
| Time Shift | Supports Time Shift |
| Hardware Interface | |
| Video Output | RCA (CVBS, L/R), HDMI Interface |
| USB Interface | 1*USB2.0 |
| Power Supply | AC INPUT 100~240V 50Hz, 10W Max |
| Package | |
| Product Size | 170*90*40mm |
| Applications | |
| Internet | USB WiFi support (M7601 chipset wifi), Megogo |
| IPTV | Supports USB import of IPTV programs (txt, xml, m3u files) |
Additional Information
- Supports various video decoding formats including H.265 for high efficiency.
- User-friendly interface with an electronic program guide for easy navigation.
- Allows for extensive customization with features such as program editing and favorite groups.
- Equipped with multiple output options including HDMI for high-quality video and audio transmission.
