H05VV-U H05VV-R NYM Single Core PVC Insulated BVV Electrical Wires
Inquire NowDescription
The H05VV-U H05VV-R NYM Single Core PVC Insulated BVV Electrical Wires are designed for durability and high performance in various electrical applications. Constructed with plain annealed copper wires, these cables provide excellent conductivity and are available in a range of insulation and sheath colors to suit different installation requirements. With a voltage rating of 300/500V and compliance to international standards such as IEC 60227 and GB/T 5023-2008, these wires are ideal for general-purpose installations. Enhanced with an additional layer of insulation, they offer better protection against wear, oil, acids, and alkaline conditions, making them suitable for use in raceways while ensuring safety and reliability.
Specifications
| Items No | Description of Cables |
|---|---|
| Conductor Material | Plain Annealed Copper Wires, solid class 1, or strand class 2. |
| Insulation Material | PVC (Polyvinyl Chloride). |
| Insulation Color | Brown, red, yellow, blue, green, black, white, grey, yellow/green, or others. |
| Sheath Material | PVC (Polyvinyl Chloride). |
| Sheath Color | Brown, red, yellow, blue, green, black, white, grey, yellow/green, or others. |
| Core Number | Single Core, 1 core, 1C. |
| Production Size | 1.5~240 mm². |
| Voltage Rate | 300/500V (U0/U). |
| Production Standard | IEC 60227, GB/T 5023-2008, JB/T 8734-2016, or others. |
| Working Temperature | -15℃ to +70℃; customized products available up to 90℃ or 105℃. |
| Min. Bending Radius | 5 x Outer Diameter of Cables. |
| Product Packing | 100 meters per roll, packaged on a plastic reel, wooden pallet, or wooden drum. |
| Delivery Time | Within 3-5 working days upon receipt of the deposit. |
Additional Information
Application Selling Point: The H05VV-U H05VV-R NYM Single Core PVC Insulated BVV Electrical Wires are specifically designed for general-purpose electrical installations where safety and performance are critical. They are suitable for installation within raceways, providing robust protection against environmental factors, while ensuring compliance with established electrical standards.
