HCDPY 1 Pole 30A 120V Electrical Contactor for Electric Definite Purpose AC Contactor
Inquire NowDescription
The HCDPY 1 Pole 30A 120V Electrical Contactor is designed for electric motors and various definite purpose applications. This high-performance contactor is ideal for commercial use, including air conditioning, refrigeration, resistive heating, and lighting. Built to meet or exceed the electrical and mechanical standards in the USA and Canada, it offers reliable operation in demanding environments. With its robust design and efficient functionality, the HCDPY contactor provides a cost-effective solution for your electrical needs.
Specifications
| Attribute | Value |
|---|---|
| FLA | 30 |
| Poles | 1 |
| Resistive Amps | 40 |
| Coil Voltage | 120V |
| Hertz | 50/60 |
| Locked Rotor Amps 240/480/600 | 180/150/120 |
Additional Information
The HCDP series Definite Purpose Contactors are equipped with silver cadmium oxide contacts and are available in a range from 20 to 90 FLA. They can operate under a temperature range of -40°F to +150°F (-40°C to +65°C) and include several coil voltage options: 24, 110/120, 208/240, and 277 VAC. The contactors feature termination options such as #10-32 screw for certain models and Box Lug for others. Additionally, they are UL listed, ensuring high standards of safety and reliability.
Application: These contactors are perfect for applications where low-cost, high-performance solutions are essential.
