Heavy Duty Front Loader ZL50GN 5 Ton Loader Capacity 3.0m3 Bucket
Inquire NowDescription
The Heavy Duty Front Loader ZL50GN is designed for superior performance with a remarkable 5-ton loader capacity and a 3.0m³ bucket. This robust loader features a high-strength wear-resistant bucket design, which significantly enhances its durability and longevity. Crafted from high-strength steel plates, the bucket improves wear and impact resistance by over 30%, ensuring it withstands the toughest conditions.
Engineered with specially enhanced critical portions, the loader incorporates a reinforcement ribbed plate structure that prevents distortion and deformation during heavy usage. Optimized boom hinges reduce dumping impact by 30%, improving overall reliability for the bucket and boom assembly. Daily maintenance is made easy, allowing the machine to remain in excellent working condition at all times, maximizing efficiency and operational readiness.
Specifications
| Description | Unit | Parameter Value |
|---|---|---|
| Rated operating load | kg | 5000 |
| Bucket capacity | m³ | 2.5~4.5 |
| Machine weight | kg | 17500±300 |
| Dump clearance at maximum lift | mm | 3100~3780 |
| Reach at maximum lift | mm | 1100~1220 |
| Wheel base | mm | 3300 |
| Tread | mm | 2250 |
| Max.breakout force | kN | 175±5 |
| Max.horse power | kW | 162±5 |
| Hydraulic cycle time-raise | s | ≤6 |
| Total hydraulic cycle time | s | ≤10.5 |
| Min. turning radius over tyres | mm | 5925±50 |
| Articulation angle | ° | 38 |
| Gradeability | ° | 30 |
| Tyre size | 23.5-25-16PR | |
| Overall machine dimension L×W×H | mm | 8225×3016×3515 |
| Model | WD10G220E21 | |
| Rated Power | kW | 162 |
| Travel Speed | Ⅰ-gear(F/R) | 13/17km/h |
| Ⅱ-gear(F) |
Additional Information
- High strength wear-resistant bucket design.
- Designed for optimal reliability and operational efficiency.
- Easy and convenient daily maintenance.
