HEAVY-DUTY FULL-MOTION TV WALL MOUNT

Inquire Now

The new solid large full motion mount is constructed with high gauge steel that designed for most 37″-90″ flat panel TVs up to 75kg/165lbs. This mount allows you to have your flat panel TV tilted for glare control or optimum viewing angle, pulled out from the wall (635mm extension) and angled towards a separate viewing area. This pre-assembled arm comes complete with integrated cable management and decorative covers to ensure an elegant and tidy look.

FEATURES

  • ●Quick-Release Latch: locks/unlocks the display in place

  • ●Swiveling Arm(s): offer(s) maximum viewing flexibility (makes every seat the best seat)

  • ●Free-Tilting Design: for multiple monitor viewing angles

  • ●Built-In Level Adjustment: ensures perfect positioning

  • ●Cable Management: elegantly hides any cables that are attached to displays

SPECIFICATION

Product Category: Full-motion TV Wall Mount
Rank: Standard
Material: Steel
Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,Wall Plate THK=3mm pickling sheet (Bracket Arm THK=0.059″ cold-rolled sheet,Wall Plate THK=0.12″ pickling sheet)
Pipe Size: 40x25x1.5mm (1.6″x0.98″x0.059″)
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 635x885x430mm (25″x34.8″x16.9″)
Fit Screen Size: 37″-90″
Fit Curved TV: Yes
Mounting Hole Pattern : VESA & Universal
VESA Compatible: 200×200,300×300,400×200,400×400,600×400,800×400
Max. VESA: 800×400
Weight Capacity: 75kg (165lbs)
Strength Tested: 3 Times Approved
Profile: 69~635mm (2.7″~25″)
Tilt Range: ＋5°～-15°
Swivel Range: +60°~-60°
Screen Level: +3°~-3°
Screen Freely Tilting: No
Installation: Double Stud(406mm/450mm),Solid Wall
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
Cable Management: Yes
Anti-theft: No
Bubble Level: Hook-on Bubble Level(Included in Components Package)
Accessory Kit Package: Normal/Ziplock Polybag,Compartment Polybag
